| SSMM | MATERIAL ALLOY | AVAILABLE SHEET | AVAILABLE SHEET | AVAILABLE THICKNESS | SWM | LWM | STRAND | MESH WEIGHT PER SQ.FT IN KGS | OPEN AREA | COVERING AREA | ||
| MARK | SPECIFICATION | WIDTH IN mm | LENGTH IN mm | mm | mm | mm | mm | mm | 1.5 mm THK | 2.0 mm THK | % | % |
| 2201 | IS:513 OR IS: 1079DD | 1220 TO 1525 mm | 2400 TO 4000 mm | 1.5 | 2 | 40 | 105 | 10 | 0.55 | 0.73 | 46 | 54 |
| 2202 | IS:513 OR IS: 1079DD | 1220 TO 1525 mm | 2400 TO 4000 mm | 1.5 | 2 | 37 | 77 | 9.3 | 0.55 | 0.73 | 46 | 54 |
| 2203 | IS:513 OR IS: 1079DD | 1220 TO 1525 mm | 2400 TO 4000 mm | 1.5 | 2 | 21 | 43 | 9.3 | 0.97 | 1.29 | 7 | 93 |
| 2204 | IS:513 OR IS: 1079DD | 1220 TO 1525 mm | 2400 TO 4000 mm | N.A | 2 | 53 | 136 | 14 | N.A | 0.77 | 43 | 57 |
| 2205 | IS:513 OR IS: 1079DD | 1220 TO 1525 mm | 2400 TO 4000 mm | N.A | 2 | 60 | 194 | 22.5 | N.A | 1.09 | 21 | 79 |
| 2205-A | IS:513 OR IS: 1079DD | 1220 TO 1525 mm | 2400 TO 4000 mm | N.A | 2 | 65 | 194 | 20.5 | N.A | 0.92 | 33 | 67 |
| 2206 | IS:513 OR IS: 1079DD | 1220 TO 1525 mm | 2400 TO 4000 mm | 1.5 | 2 | 24 | 63 | 8 | 0.73 | 0.97 | 29 | 71 |
| 2207 | IS:513 OR IS: 1079DD | 1220 TO 1525 mm | 2400 TO 4000 mm | 1.5 | 2 | 13 | 39 | 2.2 | 0.37 | 0.49 | 62 | 38 |
| 2209 | IS:513 OR IS: 1079DD | 1220 TO 1525 mm | 2400 TO 4000 mm | 1.5 | 2 | 17 | 25 | 6.6 | 0.85 | 1.13 | 18 | 82 |
| 2210 | IS:513 OR IS: 1079DD | 1220 TO 1525 mm | 2400 TO 4000 mm | 1.5 | 2 | 12 | 45 | 5.7 | 1.04 | 1.39 | 1 | 99 |
| 2211 | IS:513 OR IS: 1079DD | 1220 TO 1525 mm | 2400 TO 4000 mm | 1.5 | 2 | 9 | 45 | 3.9 | 0.95 | 1.26 | 9 | 91 |
| 2212 | IS:513 OR IS: 1079DD | 1220 TO 1525 mm | 2400 TO 4000 mm | 1.5 | 2 | 14 | 25 | 2.2 | 0.34 | 0.46 | 65 | 35 |
| 2214 | IS:513 OR IS: 1079DD | 1220 TO 1525 mm | 2400 TO 4000 mm | N.A | 2 | 37 | 77 | 12.2 | N.A | 0.96 | 30 | 70 |
| 2215 | IS:513 OR IS: 1079DD | 1220 TO 1525 mm | 2400 TO 4000 mm | 1.5 | 2 | 37 | 196 | 15 | 0.89 | 1.18 | 15 | 85 |
| 2216 | IS:513 OR IS: 1079DD | 1220 TO 1525 mm | 2400 TO 4000 mm | 1.5 | 2 | 35 | 115.5 | 10.7 | 0.67 | 0.89 | 35 | 65 |
| 2217 | IS:513 OR IS: 1079DD | 1220 TO 1525 mm | 2400 TO 4000 mm | 1.5 | 2 | 13 | 50.4 | 2.8 | 0.47 | 0.63 | 53 | 47 |
| 2217-A | IS:513 OR IS: 1079DD | 1220 TO 1525 mm | 2400 TO 4000 mm | 1.5 | 2 | 13 | 50.4 | 4.2 | 0.71 | 0.94 | 31 | 69 |
| 2225 | IS:513 OR IS: 1079DD | 1220 TO 1525 mm | 2400 TO 4000 mm | N.A | 2 | 51.5 | 161 | 24 | N.A | 1.36 | 3 | 97 |
| 2228 | IS:513 OR IS: 1079DD | 1220 TO 1525 mm | 2400 TO 4000 mm | N.A | 2 | 9.3 | 46 | 2.8 | N.A | 0.88 | 36 | 64 |
| 2229 | IS:513 OR IS: 1079DD | 1220 TO 1525 mm | 2400 TO 4000 mm | N.A | 2 | 49.3 | 115 | 18.5 | N.A | 1.10 | 21 | 79 |
| 2230 | IS:513 OR IS: 1079DD | 1220 TO 1525 mm | 2400 TO 4000 mm | 1.5 | 2 | 35 | 130 | 10.5 | 0.66 | 0.88 | 36 | 64 |
| 2231 | IS:513 OR IS: 1079DD | 1220 TO 1525 mm | 2400 TO 4000 mm | 0.5 | 1 | 8.5 | 15 | 1.2 | 0.10 | 0.21 | 68 | 32 |
| 2232 | IS:513 OR IS: 1079DD | 1220 TO 1525 mm | 2400 TO 4000 mm | 1 | 1.5 | 20 | 40 | 2 | 0.15 | 0.22 | 76 | 24 |
